SCHMIDT® ManualPress 3 RZ with mechanical stroke release
- with stroke release
- with external release button
- with return stroke lock
- with emergency release
- with piece counter
Features of the SCHMIDT® ManualPress 3 RZ rack and pinion press
- Force max. 2.4 kN
- Stroke 100 mm
- Reach 86 mm
- Working height 80 – 210 mm
Mechanical stroke release as a safety concept for hand lever presses
At SCHMIDT Technology, safety has always been a top priority, even on a small scale. The familiar options for process safety are complemented by protection against injuries.
Monotonous, manually operated press applications can become a source of danger, with potentially serious injuries.
The solution is to equip our hand lever presses with clever mechanics. This turns them into safety devices with two-hand operation for ram movement.
- Locking function over the entire ram stroke
- Stroke release also optionally possible via external button
- Self-locking locking function (spring-loaded)
- Tamper-proof locking button
- Retrofit installation of the return stroke lock possible
- Cam-guided axle clamping (patented)
Further information about the SCHMIDT® ManualPress family of mechanical hand lever presses can be found under products.
